The Hikvision DS-K3GL606WX-WE Smart Sliding Gate Opener is a powerful and intelligent gate automation solution designed to provide secure, convenient, and reliable access to residential compounds, commercial buildings, gated communities, warehouses, and industrial premises. Engineered to operate sliding gates weighing up to 600 kg, this advanced gate motor combines efficient mechanical performance with modern connectivity and integrated access control technology.

Featuring built in Wi-Fi and Ethernet connectivity, the system supports network-based management and integration with compatible security equipment. Furthermore, its battery driven operation helps maintain gate functionality during electricity interruptions when the required batteries are correctly installed and charged.

With intelligent features such as pedestrian mode, soft start and stop, component self diagnostics, and multiple access control options, the system offers a comprehensive solution for automated gate operation.

Powerful Sliding Gate Automation

The Hikvision DS-K3GL606WX-WE features a brushed motor designed to automate sliding gates weighing up to 600 kg and measuring up to 20 metres in length.

Its maximum opening speed reaches 0.6 metres per second under specified operating conditions. Consequently, the system can provide convenient entry and exit for vehicles in residential compounds and commercial premises.

Additionally, the motor delivers a starting push force of 30 kgf and a rated push force of 17 kgf. These capabilities support reliable movement when the gate is properly installed, balanced, and maintained.

Built in Wi-Fi and Smart Network Connectivity

The gate opener includes integrated Wi-Fi and a 10/100 Mbps Ethernet interface, enabling connection to compatible networking infrastructure.

Furthermore, Hik-Connect support provides smart management capabilities, while the optional 4G connectivity offers additional installation flexibility where supported.

The system supports:

• Built in Wi-Fi connectivity.
• 10/100 Mbps Ethernet networking.
• Hik Connect integration.
• Optional 4G connectivity.
• PC web configuration.
• Mobile web configuration.
• Access point mode for convenient setup.

These networking features make the gate opener suitable for modern automated entrance systems requiring centralized management and integration.

Battery Driven Operation and Power Backup

The Hikvision smart sliding gate opener operates using two 12V 7Ah batteries, which are essential for normal system operation. Its intelligent low power mode helps manage battery consumption during electricity interruptions. As a result, the system can maintain longer standby periods and support additional opening and closing cycles, depending on battery condition and operating requirements.

Additionally, the system supports a 100–240V AC power supply, allowing installation in standard electrical environments. Important: Two compatible 12V 7Ah batteries are required and must be purchased separately because they are not included with the gate opener.

Advanced Access Control Integration

The DS-K3GL606WX-WE includes an integrated access control system designed to support modern security installations. When connected to compatible external access control readers and accessories, the system can support PIN-based access, card authentication, and QR code verification.

Furthermore, its integration capabilities allow connection with compatible video intercoms, alarm systems, and access control equipment. The system supports up to 250,000 cards, 500,000 events, and 3,000 remote keyfobs, making it suitable for installations ranging from private residential compounds to larger controlled access environments.

Intelligent Safety and Gate Movement Features

The Hikvision DS-K3GL606WX-WE incorporates several intelligent functions designed to improve gate operation and user convenience. Its soft start and stop functionality supports smoother gate movement, while the pedestrian mode allows partial gate opening for pedestrian access.

Additionally, the system supports reopening functionality, infrared safety connections, emergency inputs, and flashing warning light integration. Component self diagnostics also help installers identify operating conditions and potential system faults during maintenance. For safe operation, compatible safety sensors and other required protective accessories should be installed according to the manufacturer’s instructions.

Durable Design for Outdoor Installations

The gate opener features an IPX5 protection rating, providing resistance against water jets under specified test conditions. Furthermore, its operating temperature range of -15°C to 55°C makes it suitable for a variety of residential and commercial installation environments.

Its compact housing is designed for installation alongside compatible sliding gate systems. However, proper positioning, drainage, mounting, and electrical protection remain important for reliable long term operation.

Key Features and Benefits

• 600 kg maximum gate capacity: Supports heavy residential and commercial sliding gates.
• Maximum gate length of 20 metres: Suitable for a wide range of entrance installations.
• Fast gate movement: Opening speed of up to 0.6 m/s under specified conditions.
• Built-in Wi-Fi: Enables wireless network connectivity.
• Ethernet interface: Supports wired network integration.
• Hik-Connect support: Provides compatible smart management functionality.
• Battery-driven operation: Uses two 12V 7Ah batteries for normal operation and backup capability.
• Integrated access controller: Supports multiple authentication methods with compatible accessories.
• Remote keyfob support: Accommodates up to 3,000 compatible wireless keyfobs.
• Pedestrian mode: Allows convenient partial gate opening.
• Soft start and stop: Promotes smoother gate movement.
• Component self-diagnostics: Supports easier troubleshooting and maintenance.
• IPX5 protection: Provides resistance against water ingress under specified conditions.
• Security system integration: Supports compatible intercom, alarm, and access control systems.

Ideal Applications

The Hikvision DS-K3GL606WX-WE is suitable for:

• Residential homes and private compounds.
• Gated communities and residential estates.
• Commercial office buildings.
• Warehouses and distribution centres.
• Schools, colleges, and institutions.
• Industrial premises and factories.
• Apartment complexes and parking entrances.
• Commercial properties requiring controlled vehicle access.

Why Choose the Hikvision DS-K3GL606WX-WE?

The Hikvision DS-K3GL606WX-WE combines powerful gate automation, intelligent network connectivity, and advanced access control functionality in one integrated system.

Unlike basic gate motors that provide only conventional opening and closing functions, this model supports network connectivity, smart configuration, security system integration, and multiple authentication methods.

Furthermore, its battery-driven design, pedestrian mode, self-diagnostic functions, and compatibility with external safety devices make it a practical choice for modern gate automation installations.

Whether upgrading an existing sliding gate or developing a new automated entrance system, the Hikvision DS-K3GL606WX-WE provides a versatile solution for convenient and controlled property access.
