• Single-Channel PoE Relay Function: Supports one-channel input and one-channel output.
• Extended Transmission Mode: The PSE (Power Sourcing Equipment) output interface includes an EXTEND mode, allowing a single-stage network transmission distance of up to 250 meters when enabled.
• Reliable Connectivity: Utilizes standard Cat. 5e twisted pair cables. In 10/100 Mbps mode, the repeater supports up to a four-stage cascade, achieving a maximum transmission distance of 500 meters (for terminal power consumption below 5W). When using EXTEND mode, the maximum transmission distance reaches 400 meters (for terminal power consumption below 5W).

• Support EXTEND mode of PSE (Power Sourcing Equipment) output interface. The transmission distance of single-stage network can be extended to 250 meters when the EXTEND mode is enabled.
• Standard Cat. 5e twisted pair. For 100 Mbps mode, the repeater supports 4-stage cascade and the max. transmission distance reaches 500 meters (terminal power consumption < 5W). For EXTEND mode, the max. transmission distance reaches 400 meters (terminal power consumption < 5W).
• IEEE802.3at and IEEE802.3af are supported for PoE output.
• 10/100BaseT(X) (RJ45 interface).
• IEEE802.3, IEEE802.3u and IEEE802.3x network standards available.
• Store-and-forward switching method.
• The time delay of data exchange is shorter than 5 microseconds.
• The working temperature range for wide temperature range models is within -30˚C to 70˚C.
• Solid metal case of high strength.
